Documentez votre infrastructure

· 33 minutes de lecture
Documentez votre infrastructure

As Built Report est un framework écrit en PowerShell pour générer la documentation, aux formats HTML, XML, ou Microsft Word, de la configuration de votre infrastructure.

Le projet As Built Report a été créé par Tim Carman et Matt Allford en 2017. Ce projet vise à produire une documentation automatisée, dans plusieurs formats de documents, et ce, pour un certain nombre de fournisseurs et de technologies.

As Built Report permet de documenter les configurations suivantes :

  • VMware vSphere
  • VMware NSXv
  • Cisco UCS Manager
  • PureStorage FlashArray
  • Nutanix Prism
  • VMware ESXi
  • Rubrik CDM
Find-Module -Name AsBuiltReport.* -Repository PSGallery

Version              Name                                Repository           Description
-------              ----                                ----------           -----------
1.1.3                AsBuiltReport.VMware.vSphere        PSGallery            A PowerShell module to generate an as built report on the configuration of VMware vSphere.
0.4.1                AsBuiltReport.VMware.NSXv           PSGallery            A PowerShell module to generate as built reports on the configuration of VMware NSX Datacenter.
0.2.1                AsBuiltReport.Cisco.UcsManager      PSGallery            A PowerShell module to generate an as built report on the configuration of Cisco UCS Manager.
0.4.1                AsBuiltReport.PureStorage.FlashArr… PSGallery            A PowerShell module to generate an as built report on the configuration of Pure Storage FlashArray Devices
1.1.0                AsBuiltReport.Nutanix.PrismElement  PSGallery            A PowerShell module to generate an as built report on the configuration of Nutanix Prism Element.
1.0.0                AsBuiltReport.VMware.ESXi           PSGallery            A PowerShell module to generate an as built report on the configuration of VMware ESXi servers.
0.0.7                AsBuiltReport.Rubrik.CDM            PSGallery            A PowerShell module to generate an as built report on the configuration of Rubrik.

D'autres modules sont disponibles sur le dépôt Github.

L'installation est très simple :

install-module AsBuiltReport

N'oubliez pas d'installer PowerCLI  pour le reporting VMware

Install-Module -Name VMware.PowerCLI

Pour éviter les erreurs de certificat :

Set-PowerCLIConfiguration -InvalidCertificateAction Ignore -Confirm:$false

Pour générer votre rapport VMware vSphere

New-AsBuiltReport -Report VMware.vSphere -Target <FQDN de votre vCENTER>  -Credential (get-credential) -Format HTML,Word -OutputPath ‘D:\reports’ -TimeStamp -EnableHealthchecks

Et voilà le rapport

Sample vSphere As-Built Report











Demo VMware vSphere Report
Computacenter Demo



























Author:Julien Mousqueton
Date:15 July 2020
Version:1.0

Table of Contents

1192.168.1.110
1.1   vCenter Server
1.1.1      Database Settings
1.1.2      Mail Settings
1.1.3      Historical Statistics
1.1.4      Licensing
1.1.5      SSL Certificate
1.1.6      Roles
1.2   Clusters
1.2.1      New Cluster
1.2.1.1         HA Configuration
1.2.1.2         DRS Configuration
1.2.1.3         Permissions
1.2.2      Test Cluster
1.2.2.1         HA Configuration
1.2.2.2         DRS Configuration
1.2.2.3         Permissions
1.2.3      VSAN-Cluster
1.2.3.1         HA Configuration
1.2.3.2         DRS Configuration
1.2.3.2.1            DRS Cluster Groups
1.2.3.2.2            DRS VM/Host Rules
1.2.3.2.3            DRS Rules
1.2.3.3         Update Manager Baselines
1.2.3.4         Permissions
1.3   Resource Pools
1.4   Hosts
1.4.1      192.168.1.111
1.4.1.1         Hardware
1.4.1.1.1            Boot Devices
1.4.1.1.2            PCI Devices
1.4.1.2         System
1.4.1.2.1            Licensing
1.4.1.2.2            Host Profile
1.4.1.2.3            Image Profile
1.4.1.2.4            Time Configuration
1.4.1.2.5            Syslog Configuration
1.4.1.2.6            Update Manager Compliance
1.4.1.3         Storage
1.4.1.3.1            Datastores
1.4.1.4         Network
1.4.1.4.1            Physical Adapters
1.4.1.4.2            Cisco Discovery Protocol
1.4.1.4.3            VMkernel Adapters
1.4.1.4.4            Standard Virtual Switches
1.4.1.4.5            Virtual Switch Security Policy
1.4.1.4.6            Virtual Switch NIC Teaming
1.4.1.4.7            Virtual Port Groups
1.4.1.4.8            Virtual Port Group Security Policy
1.4.1.4.9            Virtual Port Group NIC Teaming
1.4.1.5         Security
1.4.1.5.1            Lockdown Mode
1.4.1.5.2            Services
1.4.1.5.3            Authentication Services
1.4.2      192.168.1.112
1.4.2.1         Hardware
1.4.2.1.1            Boot Devices
1.4.2.1.2            PCI Devices
1.4.2.2         System
1.4.2.2.1            Licensing
1.4.2.2.2            Host Profile
1.4.2.2.3            Image Profile
1.4.2.2.4            Time Configuration
1.4.2.2.5            Syslog Configuration
1.4.2.2.6            Update Manager Compliance
1.4.2.3         Storage
1.4.2.3.1            Datastores
1.4.2.4         Network
1.4.2.4.1            Physical Adapters
1.4.2.4.2            Cisco Discovery Protocol
1.4.2.4.3            VMkernel Adapters
1.4.2.4.4            Standard Virtual Switches
1.4.2.4.5            Virtual Switch Security Policy
1.4.2.4.6            Virtual Switch NIC Teaming
1.4.2.4.7            Virtual Port Groups
1.4.2.4.8            Virtual Port Group Security Policy
1.4.2.4.9            Virtual Port Group NIC Teaming
1.4.2.5         Security
1.4.2.5.1            Lockdown Mode
1.4.2.5.2            Services
1.4.2.5.3            Authentication Services
1.4.3      192.168.1.113
1.4.3.1         Hardware
1.4.3.1.1            Boot Devices
1.4.3.1.2            PCI Devices
1.4.3.2         System
1.4.3.2.1            Licensing
1.4.3.2.2            Host Profile
1.4.3.2.3            Image Profile
1.4.3.2.4            Time Configuration
1.4.3.2.5            Syslog Configuration
1.4.3.2.6            Update Manager Compliance
1.4.3.3         Storage
1.4.3.3.1            Datastores
1.4.3.4         Network
1.4.3.4.1            Physical Adapters
1.4.3.4.2            Cisco Discovery Protocol
1.4.3.4.3            VMkernel Adapters
1.4.3.4.4            Standard Virtual Switches
1.4.3.4.5            Virtual Switch Security Policy
1.4.3.4.6            Virtual Switch NIC Teaming
1.4.3.4.7            Virtual Port Groups
1.4.3.4.8            Virtual Port Group Security Policy
1.4.3.4.9            Virtual Port Group NIC Teaming
1.4.3.5         Security
1.4.3.5.1            Lockdown Mode
1.4.3.5.2            Services
1.4.3.5.3            Authentication Services
1.5   Distributed Virtual Switches
1.5.1      DSwitch
1.5.1.1         General Properties
1.5.1.2         Uplinks
1.5.1.3         Security
1.5.1.4         Traffic Shaping
1.5.1.5         Port Groups
1.5.1.6         Port Group Security
1.5.1.7         Port Group NIC Teaming
1.5.1.8         Private VLANs
1.5.2      DSwitch 1
1.5.2.1         General Properties
1.5.2.2         Security
1.5.2.3         Traffic Shaping
1.5.2.4         Port Groups
1.5.2.5         Port Group Security
1.5.2.6         Port Group NIC Teaming
1.6   vSAN
1.6.1      VSAN-Cluster
1.7   Storage
1.7.1      Datastore Specifications
1.8   Virtual Machines
1.8.1      Test_1
1.8.2      Test_2
1.8.3      Test_3
1.8.4      VM Snapshots
1.9   VMware Update Manager
1.9.1      Baselines

1 192.168.1.110

1.1 vCenter Server

The following section provides detailed information on the configuration of vCenter server 192.168.1.110.

Name192.168.1.110
IP Address192.168.1.110
Version6.5.0
Build5973321
OS Typelinux-x64
Instance Id42
Password Expiry in Days30
HTTP Port80
HTTPS Port443
Platform Services Controller192.168.1.110

1.1.1 Database Settings

Database Typeembedded
Data Source NameVMware VirtualCenter
Maximum Database Connections50

1.1.2 Mail Settings

SMTP Serversmtp.gmail.com
SMTP Port25
Mail Sender

1.1.3 Historical Statistics

Interval DurationInterval EnabledSave DurationStatistics Level
5 MinutesTruePast day1
30 MinutesTruePast week1
2 HoursTruePast month1
1 DayTruePast year1

1.1.4 Licensing

Product NameLicense KeyTotalUsedAvailable
VMware vCenter Server 6 Standard*****-*****-*****-0J9U6-0NF2M211
VMware vSAN Enterprise*****-*****-*****-061A0-2NA7H1064
VMware vSphere 6 Enterprise Plus*****-*****-*****-079HM-29JHN3006294

1.1.5 SSL Certificate

CountryUS
StateCalifornia
LocalityPalo Alto
OrganizationVMware
Organizational UnitVMware Engineering
Emailvmca@vmware.com
Validity5 Years

1.1.6 Roles

NameSystem Role
AdminTrue
AnonymousTrue
com.vmware.Content.AdminFalse
DatastoreConsumerFalse
InventoryService.Tagging.TaggingAdminFalse
NetworkConsumerFalse
NoAccessTrue
NoCryptoAdminTrue
ReadOnlyTrue
ResourcePoolAdministratorFalse
ViewTrue
VirtualMachineConsoleUserFalse
VirtualMachinePowerUserFalse
VirtualMachineUserFalse
VMwareConsolidatedBackupUserFalse

1.2 Clusters

The following section provides information on the configuration of each vSphere HA/DRS cluster.

NameDatacenterHost CountHA EnabledDRS EnabledvSAN EnabledEVC ModeVM Swap File PolicyVM Count
New ClusterDatacenter0TrueTrueFalse WithVM0
Test ClusterDatacenter0FalseFalseFalseintel-ivybridgeWithVM0
VSAN-ClusterDatacenter3TrueTrueTrue WithVM3

1.2.1 New Cluster

The following table details the cluster configuration for cluster New Cluster.

NameNew Cluster
DatacenterDatacenter
Number of Hosts0
Number of VMs0
HA EnabledTrue
DRS EnabledTrue
vSAN EnabledFalse
EVC Mode
VM Swap File PolicyWithVM
Connected Hosts

1.2.1.1 HA Configuration

The following table details the vSphere HA configuration for cluster New Cluster.

HA EnabledTrue
HA Admission Control EnabledTrue
HA Failover Level1
HA Restart PriorityMedium
HA Isolation ResponseDoNothing
Heartbeat Selection PolicyallFeasibleDsWithUserPreference
Heartbeat Datastores

1.2.1.2 DRS Configuration

The following table details the vSphere DRS configuration for cluster New Cluster.

DRS EnabledTrue
DRS Automation LevelFullyAutomated
DRS Migration Threshold3

VM Distribution
Memory Metric for Load Balancing
CPU Over-Commitment

1.2.1.3 Permissions

The following table details the permissions assigned to cluster New Cluster.

User/GroupIs Group?RoleDefined InPropagate
VSPHERE.LOCAL\vpxd-extension-0cd516db-cbaa-434b-8b6f-90452748e378FalseAdminDatacentersTrue
VSPHERE.LOCAL\vpxd-0cd516db-cbaa-434b-8b6f-90452748e378FalseAdminDatacentersTrue
VSPHERE.LOCAL\vsphere-webclient-0cd516db-cbaa-434b-8b6f-90452748e378FalseReadOnlyDatacentersTrue
VSPHERE.LOCAL\AdministratorFalseAdminDatacentersTrue
VSPHERE.LOCAL\AdministratorsTrueAdminDatacentersTrue

1.2.2 Test Cluster

The following table details the cluster configuration for cluster Test Cluster.

NameTest Cluster
DatacenterDatacenter
Number of Hosts0
Number of VMs0
HA EnabledFalse
DRS EnabledFalse
vSAN EnabledFalse
EVC Modeintel-ivybridge
VM Swap File PolicyWithVM
Connected Hosts

1.2.2.1 HA Configuration

The following table details the vSphere HA configuration for cluster Test Cluster.

HA EnabledFalse
HA Admission Control EnabledFalse
HA Failover Level1
HA Restart PriorityMedium
HA Isolation ResponseDoNothing
Heartbeat Selection PolicyallFeasibleDsWithUserPreference
Heartbeat Datastores

1.2.2.2 DRS Configuration

The following table details the vSphere DRS configuration for cluster Test Cluster.

DRS EnabledFalse
DRS Automation LevelFullyAutomated
DRS Migration Threshold3

VM Distribution
Memory Metric for Load Balancing
CPU Over-Commitment

1.2.2.3 Permissions

The following table details the permissions assigned to cluster Test Cluster.

User/GroupIs Group?RoleDefined InPropagate
VSPHERE.LOCAL\vpxd-extension-0cd516db-cbaa-434b-8b6f-90452748e378FalseAdminDatacentersTrue
VSPHERE.LOCAL\vpxd-0cd516db-cbaa-434b-8b6f-90452748e378FalseAdminDatacentersTrue
VSPHERE.LOCAL\vsphere-webclient-0cd516db-cbaa-434b-8b6f-90452748e378FalseReadOnlyDatacentersTrue
VSPHERE.LOCAL\AdministratorFalseAdminDatacentersTrue
VSPHERE.LOCAL\AdministratorsTrueAdminDatacentersTrue

1.2.3 VSAN-Cluster

The following table details the cluster configuration for cluster VSAN-Cluster.

NameVSAN-Cluster
DatacenterDatacenter
Number of Hosts3
Number of VMs3
HA EnabledTrue
DRS EnabledTrue
vSAN EnabledTrue
EVC Mode
VM Swap File PolicyWithVM
Connected Hosts192.168.1.111, 192.168.1.112, 192.168.1.113

1.2.3.1 HA Configuration

The following table details the vSphere HA configuration for cluster VSAN-Cluster.

HA EnabledTrue
HA Admission Control EnabledTrue
HA Failover Level1
HA Restart PriorityMedium
HA Isolation ResponseDoNothing
Heartbeat Selection PolicyallFeasibleDsWithUserPreference
Heartbeat Datastores

1.2.3.2 DRS Configuration

The following table details the vSphere DRS configuration for cluster VSAN-Cluster.

DRS EnabledTrue
DRS Automation LevelFullyAutomated
DRS Migration Threshold3

VM Distribution1
Memory Metric for Load Balancing100
CPU Over-Commitment
1.2.3.2.1 DRS Cluster Groups
NameGroup TypeMembers
Test_VMsVMGroupTest_1, Test_2
Prod_HostsVMHostGroup192.168.1.111, 192.168.1.112, 192.168.1.113
1.2.3.2.2 DRS VM/Host Rules
NameTypeEnabledVM GroupVMHost Group
VM not on HostShouldNotRunOnFalseTest_VMsProd_Hosts
VM_to_HostShouldRunOnFalseTest_VMsProd_Hosts
1.2.3.2.3 DRS Rules
NameTypeEnabledMandatoryVirtual Machines
Test_VMsVMAntiAffinityTrueFalseTest_1, Test_2
TestVMAffinityFalseFalseTest_1, Test_2

1.2.3.3 Update Manager Baselines

NameDescriptionTypeTarget TypeLast Update TimeNumber of Patches
Critical Host Patches (Predefined)A predefined baseline for all critical patches for HostsPatchHost28/02/2017 9:35:00 PM71
Non-Critical Host Patches (Predefined)A predefined baseline for all non-critical patches for HostsPatchHost28/02/2017 9:35:00 PM236
VMware ESXi 6.5.0 U2 (vSAN 6.6.1 Update 2, build 8294253)VMware ESXi 6.5.0 U2 (vSAN 6.6.1 Update 2, build 8294253)PatchHost23/05/2018 9:28:38 AM1

1.2.3.4 Permissions

The following table details the permissions assigned to cluster VSAN-Cluster.

User/GroupIs Group?RoleDefined InPropagate
VSPHERE.LOCAL\SolutionUsersTrueReadOnlyVSAN-ClusterFalse
VSPHERE.LOCAL\vpxd-extension-0cd516db-cbaa-434b-8b6f-90452748e378FalseAdminDatacentersTrue
VSPHERE.LOCAL\vpxd-0cd516db-cbaa-434b-8b6f-90452748e378FalseAdminDatacentersTrue
VSPHERE.LOCAL\vsphere-webclient-0cd516db-cbaa-434b-8b6f-90452748e378FalseReadOnlyDatacentersTrue
VSPHERE.LOCAL\AdministratorFalseAdminDatacentersTrue
VSPHERE.LOCAL\AdministratorsTrueAdminDatacentersTrue

1.3 Resource Pools

The following section provides information on the configuration of resource pools.

NameResources
IdResourcePool-resgroup-35
ParentNew Cluster
CPU Shares LevelNormal
Number of CPU Shares4000
CPU Reservation0 MHz
CPU Expandable ReservationTrue
CPU LimitUnlimited
Memory Shares LevelNormal
Number of Memory Shares163840
Memory Reservation0 GB
Memory Expandable ReservationTrue
Memory LimitUnlimited

NameTesting
IdResourcePool-resgroup-62
ParentResources
CPU Shares LevelNormal
Number of CPU Shares4000
CPU Reservation0 MHz
CPU Expandable ReservationTrue
CPU Limit1000 MHz
Memory Shares LevelNormal
Number of Memory Shares163840
Memory Reservation0 GB
Memory Expandable ReservationTrue
Memory LimitUnlimited

NameResources
IdResourcePool-resgroup-28
ParentTest Cluster
CPU Shares LevelNormal
Number of CPU Shares4000
CPU Reservation0 MHz
CPU Expandable ReservationTrue
CPU LimitUnlimited
Memory Shares LevelNormal
Number of Memory Shares163840
Memory Reservation0 GB
Memory Expandable ReservationTrue
Memory LimitUnlimited

NameResources
IdResourcePool-resgroup-8
ParentVSAN-Cluster
CPU Shares LevelNormal
Number of CPU Shares4000
CPU Reservation6612 MHz
CPU Expandable ReservationTrue
CPU Limit6612 MHz
Memory Shares LevelNormal
Number of Memory Shares163840
Memory Reservation0.70 GB
Memory Expandable ReservationTrue
Memory Limit0.70 GB

1.4 Hosts

The following section provides information on the configuration of VMware ESXi hosts.

NameVersionBuildParentConnection StateCPU Usage MHzMemory Usage GBVM Count
192.168.1.1116.5.05969303VSAN-ClusterConnected1703.331
192.168.1.1126.5.05969303VSAN-ClusterConnected1353.331
192.168.1.1136.5.05969303VSAN-ClusterConnected1263.331

1.4.1 192.168.1.111

1.4.1.1 Hardware

The following section provides information on the host hardware configuration of 192.168.1.111.

Name192.168.1.111
ParentVSAN-Cluster
ManufacturerVMware, Inc.
ModelVMware Virtual Platform
Serial Number
Asset Tag
Processor TypeIntel(R) Xeon(R) CPU D-1528 @ 1.90GHz
HyperThreadingFalse
CPU Socket Count2
CPU Core Count2
CPU Thread Count2
CPU Speed1.9 GHz
Memory6 GB
NUMA Nodes1
NIC Count2
Maximum EVC Modeintel-broadwell
Power Management PolicyHigh Performance
Scratch Location/tmp/scratch
Bios Version6.00
Bios Release Date28/07/2017 12:00:00 AM
ESXi Version6.5.0
ESXi Build5969303
Uptime Days74.7
1.4.1.1.1 Boot Devices
Host192.168.1.111
Devicenaa.6000c29e041dd7e2fea7da7634a3eaf0
Boot Typelocal
VendorVMware
ModelVirtual disk
Size MB2048
Is SASfalse
Is SSDfalse
Is USBfalse
1.4.1.1.2 PCI Devices
VMkernel NamePCI AddressDevice ClassDevice NameVendor NameSlot Description
vmhba00000:13:00.0Serial Attached SCSI controllerPVSCSI SCSI ControllerVMware Inc.SCSI0
vmhba10000:00:07.1IDE interfacePIIX4 for 430TX/440BX/MX IDE ControllerIntel Corporation
vmnic00000:03:00.0Ethernet controllervmxnet3 Virtual Ethernet ControllerVMware Inc.Ethernet0
vmnic10000:0b:00.0Ethernet controllervmxnet3 Virtual Ethernet ControllerVMware Inc.Ethernet1

1.4.1.2 System

The following section provides information on the host system configuration of 192.168.1.111.
1.4.1.2.1 Licensing
License TypeLicense Key
VMware vSphere 6 Enterprise Plus*****-*****-*****-079HM-29JHN
1.4.1.2.2 Host Profile
NameDescription
Host Profile TestHost Profile for doco report
1.4.1.2.3 Image Profile
Image ProfileVendorInstallation Date
(Updated) ESXi-6.5.0-4564106-standardVMware, Inc.28/02/2017 9:16:02 PM
1.4.1.2.4 Time Configuration
Time ZoneNTP Service RunningNTP Server(s)
UTCFalse0.au.pool.ntp.org, 1.au.pool.ntp.org
1.4.1.2.5 Syslog Configuration
SysLog ServerPort
192.168.1.110
1.4.1.2.6 Update Manager Compliance
BaselineStatus
VMware ESXi 6.5.0 U2 (vSAN 6.6.1 Update 2, build 8294253)NotCompliant
Non-Critical Host Patches (Predefined)NotCompliant
Critical Host Patches (Predefined)NotCompliant

1.4.1.3 Storage

The following section provides information on the host storage configuration of 192.168.1.111.
1.4.1.3.1 Datastores
NameTypeVersionTotal Capacity GBUsed Capacity GBFree Space GB% Used
vsanDatastorevsan 23.982.6321.3410.98

1.4.1.4 Network

The following section provides information on the host network configuration of 192.168.1.111.

VMHost192.168.1.111
Virtual SwitchesvSwitch0
VMKernel Adaptersvmk0
Physical Adaptersvmnic0, vmnic1
VMKernel Gateway192.168.1.1
IPv6 EnabledTrue
VMKernel IPv6 Gateway
DNS Servers192.168.1.10, 8.8.8.8
Host Namevesxi65-1
Domain Name
Search Domainlab.local
1.4.1.4.1 Physical Adapters
The following table details the physical network adapters for 192.168.1.111.

Device NameMAC AddressBitrate/SecondFull DuplexWake on LAN Support
vmnic000:0c:29:57:f3:9810000TrueFalse
vmnic100:0c:29:57:f3:a210000TrueFalse
1.4.1.4.2 Cisco Discovery Protocol
NICConnectedSwitchHardware PlatformPort ID
vmnic0Truedca5f4a56b91Cisco SG200-26P (PID:SLM2024PT)-VSDgi1
vmnic1Truedca5f4a56b91Cisco SG200-26P (PID:SLM2024PT)-VSDgi1
1.4.1.4.3 VMkernel Adapters
The following table details the VMkernel adapters for 192.168.1.111

Device Namevmk0
Network LabelManagement Network
MTU1500
MAC Address00:0c:29:57:f3:98
IP Address192.168.1.111
Subnet Mask255.255.255.0
vMotion TrafficFalse
FT LoggingFalse
Management TrafficTrue
vSAN TrafficTrue
1.4.1.4.4 Standard Virtual Switches
The following sections detail the standard virtual switch configuration for 192.168.1.111.

NamevSwitch0
MTU1500
Number of Ports1536
Number of Ports Available1528
Load BalancingLoadBalanceSrcId
Failover DetectionLinkStatus
Notify SwitchesTrue
Failback EnabledTrue
Active NICsvmnic0
Standby NICs
Unused NICs
1.4.1.4.5 Virtual Switch Security Policy
vSwitchMAC Address ChangesForged TransmitsPromiscuous Mode
vSwitch0TrueTrueFalse
1.4.1.4.6 Virtual Switch NIC Teaming
vSwitchLoad BalancingFailover DetectionNotify SwitchesFailback EnabledActive NICsStandby NICsUnused NICs
vSwitch0LoadBalanceSrcIdLinkStatusTrueTruevmnic0
1.4.1.4.7 Virtual Port Groups
vSwitchPortgroupVLAN ID
vSwitch0Management Network0
vSwitch0VM Network0
1.4.1.4.8 Virtual Port Group Security Policy
vSwitchPortgroupMAC ChangesForged TransmitsPromiscuous Mode
vSwitch0VM NetworkTrueTrueFalse
vSwitch0Management NetworkTrueTrueFalse
1.4.1.4.9 Virtual Port Group NIC Teaming
vSwitchPortgroupLoad BalancingFailover DetectionNotify SwitchesFailback EnabledActive NICsStandby NICsUnused NICs
vSwitch0VM NetworkLoadBalanceSrcIdLinkStatusTrueTruevmnic0
vSwitch0Management NetworkLoadBalanceSrcIdLinkStatusTrueTruevmnic0

1.4.1.5 Security

The following section provides information on the host security configuration of 192.168.1.111.
1.4.1.5.1 Lockdown Mode
Lockdown ModeTrue
1.4.1.5.2 Services
NameLabelPolicyRunningRequired
DCUIDirect Console UIonTrueFalse
lbtdLoad-Based Teaming DaemononTrueFalse
lwsmdActive Directory ServiceonTrueFalse
ntpdNTP DaemonoffFalseFalse
pcscdPC/SC Smart Card DaemonoffFalseFalse
sfcbd-watchdogCIM ServeronFalseFalse
snmpdSNMP ServeronFalseFalse
TSMESXi ShellonTrueFalse
TSM-SSHSSHonTrueFalse
vmsyslogdSyslog ServeronTrueTrue
vmware-fdmvSphere High Availability AgentonTrueFalse
vpxaVMware vCenter AgentonTrueFalse
xorgX.Org ServeronFalseFalse
1.4.1.5.3 Authentication Services
DomainDomain MembershipTrusted Domains
LAB.LOCALOk

1.4.2 192.168.1.112

1.4.2.1 Hardware

The following section provides information on the host hardware configuration of 192.168.1.112.

Name192.168.1.112
ParentVSAN-Cluster
ManufacturerVMware, Inc.
ModelVMware Virtual Platform
Serial Number
Asset Tag
Processor TypeIntel(R) Xeon(R) CPU D-1528 @ 1.90GHz
HyperThreadingFalse
CPU Socket Count2
CPU Core Count2
CPU Thread Count2
CPU Speed1.9 GHz
Memory6 GB
NUMA Nodes1
NIC Count2
Maximum EVC Modeintel-broadwell
Power Management PolicyHigh Performance
Scratch Location/tmp/scratch
Bios Version6.00
Bios Release Date28/07/2017 12:00:00 AM
ESXi Version6.5.0
ESXi Build5969303
Uptime Days74.7
1.4.2.1.1 Boot Devices
Host192.168.1.112
Devicenaa.6000c29a60075960e1284ed911495826
Boot Typelocal
VendorVMware
ModelVirtual disk
Size MB2048
Is SASfalse
Is SSDfalse
Is USBfalse
1.4.2.1.2 PCI Devices
VMkernel NamePCI AddressDevice ClassDevice NameVendor NameSlot Description
vmhba00000:13:00.0Serial Attached SCSI controllerPVSCSI SCSI ControllerVMware Inc.SCSI0
vmhba10000:00:07.1IDE interfacePIIX4 for 430TX/440BX/MX IDE ControllerIntel Corporation
vmnic00000:03:00.0Ethernet controllervmxnet3 Virtual Ethernet ControllerVMware Inc.Ethernet0
vmnic10000:0b:00.0Ethernet controllervmxnet3 Virtual Ethernet ControllerVMware Inc.Ethernet1

1.4.2.2 System

The following section provides information on the host system configuration of 192.168.1.112.
1.4.2.2.1 Licensing
License TypeLicense Key
VMware vSphere 6 Enterprise Plus*****-*****-*****-079HM-29JHN
1.4.2.2.2 Host Profile
NameDescription
Host Profile TestHost Profile for doco report
1.4.2.2.3 Image Profile
Image ProfileVendorInstallation Date
(Updated) ESXi-6.5.0-4564106-standardVMware, Inc.28/02/2017 9:16:28 PM
1.4.2.2.4 Time Configuration
Time ZoneNTP Service RunningNTP Server(s)
UTCFalse0.au.pool.ntp.org, 1.au.pool.ntp.org
1.4.2.2.5 Syslog Configuration
SysLog ServerPort
192.168.1.110
1.4.2.2.6 Update Manager Compliance
BaselineStatus
VMware ESXi 6.5.0 U2 (vSAN 6.6.1 Update 2, build 8294253)NotCompliant
Non-Critical Host Patches (Predefined)NotCompliant
Critical Host Patches (Predefined)NotCompliant

1.4.2.3 Storage

The following section provides information on the host storage configuration of 192.168.1.112.
1.4.2.3.1 Datastores
NameTypeVersionTotal Capacity GBUsed Capacity GBFree Space GB% Used
vsanDatastorevsan 23.982.6321.3410.98

1.4.2.4 Network

The following section provides information on the host network configuration of 192.168.1.112.

VMHost192.168.1.112
Virtual SwitchesvSwitch0
VMKernel Adaptersvmk0
Physical Adaptersvmnic0, vmnic1
VMKernel Gateway192.168.1.1
IPv6 EnabledTrue
VMKernel IPv6 Gateway
DNS Servers192.168.1.10, 8.8.8.8
Host Namevesxi65-2
Domain Name
Search Domainlab.local
1.4.2.4.1 Physical Adapters
The following table details the physical network adapters for 192.168.1.112.

Device NameMAC AddressBitrate/SecondFull DuplexWake on LAN Support
vmnic000:0c:29:0a:c0:5710000TrueFalse
vmnic100:0c:29:0a:c0:6110000TrueFalse
1.4.2.4.2 Cisco Discovery Protocol
NICConnectedSwitchHardware PlatformPort ID
vmnic0Truedca5f4a56b91Cisco SG200-26P (PID:SLM2024PT)-VSDgi1
vmnic1Truedca5f4a56b91Cisco SG200-26P (PID:SLM2024PT)-VSDgi1
1.4.2.4.3 VMkernel Adapters
The following table details the VMkernel adapters for 192.168.1.112

Device Namevmk0
Network LabelManagement Network
MTU1500
MAC Address00:0c:29:0a:c0:57
IP Address192.168.1.112
Subnet Mask255.255.255.0
vMotion TrafficFalse
FT LoggingFalse
Management TrafficTrue
vSAN TrafficTrue
1.4.2.4.4 Standard Virtual Switches
The following sections detail the standard virtual switch configuration for 192.168.1.112.

NamevSwitch0
MTU1500
Number of Ports1536
Number of Ports Available1528
Load BalancingLoadBalanceSrcId
Failover DetectionLinkStatus
Notify SwitchesTrue
Failback EnabledTrue
Active NICsvmnic0
Standby NICs
Unused NICs
1.4.2.4.5 Virtual Switch Security Policy
vSwitchMAC Address ChangesForged TransmitsPromiscuous Mode
vSwitch0TrueTrueFalse
1.4.2.4.6 Virtual Switch NIC Teaming
vSwitchLoad BalancingFailover DetectionNotify SwitchesFailback EnabledActive NICsStandby NICsUnused NICs
vSwitch0LoadBalanceSrcIdLinkStatusTrueTruevmnic0
1.4.2.4.7 Virtual Port Groups
vSwitchPortgroupVLAN ID
vSwitch0Management Network0
vSwitch0VM Network0
1.4.2.4.8 Virtual Port Group Security Policy
vSwitchPortgroupMAC ChangesForged TransmitsPromiscuous Mode
vSwitch0VM NetworkTrueTrueFalse
vSwitch0Management NetworkTrueTrueFalse
1.4.2.4.9 Virtual Port Group NIC Teaming
vSwitchPortgroupLoad BalancingFailover DetectionNotify SwitchesFailback EnabledActive NICsStandby NICsUnused NICs
vSwitch0VM NetworkLoadBalanceSrcIdLinkStatusTrueTruevmnic0
vSwitch0Management NetworkLoadBalanceSrcIdLinkStatusTrueTruevmnic0

1.4.2.5 Security

The following section provides information on the host security configuration of 192.168.1.112.
1.4.2.5.1 Lockdown Mode
Lockdown ModeFalse
1.4.2.5.2 Services
NameLabelPolicyRunningRequired
DCUIDirect Console UIonTrueFalse
lbtdLoad-Based Teaming DaemononTrueFalse
lwsmdActive Directory ServiceonTrueFalse
ntpdNTP DaemonoffFalseFalse
pcscdPC/SC Smart Card DaemonoffFalseFalse
sfcbd-watchdogCIM ServeronFalseFalse
snmpdSNMP ServeronFalseFalse
TSMESXi ShellonTrueFalse
TSM-SSHSSHonTrueFalse
vmsyslogdSyslog ServeronTrueTrue
vmware-fdmvSphere High Availability AgentonTrueFalse
vpxaVMware vCenter AgentonTrueFalse
xorgX.Org ServeronFalseFalse
1.4.2.5.3 Authentication Services
DomainDomain MembershipTrusted Domains
LAB.LOCALOk

1.4.3 192.168.1.113

1.4.3.1 Hardware

The following section provides information on the host hardware configuration of 192.168.1.113.

Name192.168.1.113
ParentVSAN-Cluster
ManufacturerVMware, Inc.
ModelVMware Virtual Platform
Serial Number
Asset Tag
Processor TypeIntel(R) Xeon(R) CPU D-1528 @ 1.90GHz
HyperThreadingFalse
CPU Socket Count2
CPU Core Count2
CPU Thread Count2
CPU Speed1.9 GHz
Memory6 GB
NUMA Nodes1
NIC Count2
Maximum EVC Modeintel-broadwell
Power Management PolicyHigh Performance
Scratch Location/tmp/scratch
Bios Version6.00
Bios Release Date28/07/2017 12:00:00 AM
ESXi Version6.5.0
ESXi Build5969303
Uptime Days74.7
1.4.3.1.1 Boot Devices
Host192.168.1.113
Devicenaa.6000c2994ed56a57b2049108de88effd
Boot Typelocal
VendorVMware
ModelVirtual disk
Size MB2048
Is SASfalse
Is SSDfalse
Is USBfalse
1.4.3.1.2 PCI Devices
VMkernel NamePCI AddressDevice ClassDevice NameVendor NameSlot Description
vmhba00000:13:00.0Serial Attached SCSI controllerPVSCSI SCSI ControllerVMware Inc.SCSI0
vmhba10000:00:07.1IDE interfacePIIX4 for 430TX/440BX/MX IDE ControllerIntel Corporation
vmnic00000:03:00.0Ethernet controllervmxnet3 Virtual Ethernet ControllerVMware Inc.Ethernet0
vmnic10000:0b:00.0Ethernet controllervmxnet3 Virtual Ethernet ControllerVMware Inc.Ethernet1

1.4.3.2 System

The following section provides information on the host system configuration of 192.168.1.113.
1.4.3.2.1 Licensing
License TypeLicense Key
VMware vSphere 6 Enterprise Plus*****-*****-*****-079HM-29JHN
1.4.3.2.2 Host Profile
NameDescription
Host Profile TestHost Profile for doco report
1.4.3.2.3 Image Profile
Image ProfileVendorInstallation Date
(Updated) ESXi-6.5.0-4564106-standardVMware, Inc.28/02/2017 9:17:02 PM
1.4.3.2.4 Time Configuration
Time ZoneNTP Service RunningNTP Server(s)
UTCFalse0.au.pool.ntp.org, 1.au.pool.ntp.org
1.4.3.2.5 Syslog Configuration
SysLog ServerPort
192.168.1.110
1.4.3.2.6 Update Manager Compliance
BaselineStatus
VMware ESXi 6.5.0 U2 (vSAN 6.6.1 Update 2, build 8294253)NotCompliant
Non-Critical Host Patches (Predefined)NotCompliant
Critical Host Patches (Predefined)NotCompliant

1.4.3.3 Storage

The following section provides information on the host storage configuration of 192.168.1.113.
1.4.3.3.1 Datastores
NameTypeVersionTotal Capacity GBUsed Capacity GBFree Space GB% Used
vsanDatastorevsan 23.982.6321.3410.98

1.4.3.4 Network

The following section provides information on the host network configuration of 192.168.1.113.

VMHost192.168.1.113
Virtual SwitchesvSwitch0
VMKernel Adaptersvmk0
Physical Adaptersvmnic0, vmnic1
VMKernel Gateway192.168.1.1
IPv6 EnabledTrue
VMKernel IPv6 Gateway
DNS Servers192.168.1.10, 8.8.8.8
Host Namevesxi65-3
Domain Name
Search Domainlab.local
1.4.3.4.1 Physical Adapters
The following table details the physical network adapters for 192.168.1.113.

Device NameMAC AddressBitrate/SecondFull DuplexWake on LAN Support
vmnic000:0c:29:a2:26:0410000TrueFalse
vmnic100:0c:29:a2:26:0e10000TrueFalse
1.4.3.4.2 Cisco Discovery Protocol
NICConnectedSwitchHardware PlatformPort ID
vmnic0Truedca5f4a56b91Cisco SG200-26P (PID:SLM2024PT)-VSDgi1
vmnic1Truedca5f4a56b91Cisco SG200-26P (PID:SLM2024PT)-VSDgi1
1.4.3.4.3 VMkernel Adapters
The following table details the VMkernel adapters for 192.168.1.113

Device Namevmk0
Network LabelManagement Network
MTU1500
MAC Address00:0c:29:a2:26:04
IP Address192.168.1.113
Subnet Mask255.255.255.0
vMotion TrafficFalse
FT LoggingFalse
Management TrafficTrue
vSAN TrafficTrue
1.4.3.4.4 Standard Virtual Switches
The following sections detail the standard virtual switch configuration for 192.168.1.113.

NamevSwitch0
MTU1500
Number of Ports1536
Number of Ports Available1528
Load BalancingLoadBalanceSrcId
Failover DetectionLinkStatus
Notify SwitchesTrue
Failback EnabledTrue
Active NICsvmnic0
Standby NICs
Unused NICs
1.4.3.4.5 Virtual Switch Security Policy
vSwitchMAC Address ChangesForged TransmitsPromiscuous Mode
vSwitch0TrueTrueFalse
1.4.3.4.6 Virtual Switch NIC Teaming
vSwitchLoad BalancingFailover DetectionNotify SwitchesFailback EnabledActive NICsStandby NICsUnused NICs
vSwitch0LoadBalanceSrcIdLinkStatusTrueTruevmnic0
1.4.3.4.7 Virtual Port Groups
vSwitchPortgroupVLAN ID
vSwitch0Management Network0
vSwitch0VM Network0
1.4.3.4.8 Virtual Port Group Security Policy
vSwitchPortgroupMAC ChangesForged TransmitsPromiscuous Mode
vSwitch0VM NetworkTrueTrueFalse
vSwitch0Management NetworkTrueTrueFalse
1.4.3.4.9 Virtual Port Group NIC Teaming
vSwitchPortgroupLoad BalancingFailover DetectionNotify SwitchesFailback EnabledActive NICsStandby NICsUnused NICs
vSwitch0VM NetworkLoadBalanceSrcIdLinkStatusTrueTruevmnic0
vSwitch0Management NetworkLoadBalanceSrcIdLinkStatusTrueTruevmnic0

1.4.3.5 Security

The following section provides information on the host security configuration of 192.168.1.113.
1.4.3.5.1 Lockdown Mode
Lockdown ModeFalse
1.4.3.5.2 Services
NameLabelPolicyRunningRequired
DCUIDirect Console UIonTrueFalse
lbtdLoad-Based Teaming DaemononTrueFalse
lwsmdActive Directory ServiceonTrueFalse
ntpdNTP DaemonoffFalseFalse
pcscdPC/SC Smart Card DaemonoffFalseFalse
sfcbd-watchdogCIM ServeronFalseFalse
snmpdSNMP ServeronFalseFalse
TSMESXi ShellonTrueFalse
TSM-SSHSSHonTrueFalse
vmsyslogdSyslog ServeronTrueTrue
vmware-fdmvSphere High Availability AgentonTrueFalse
vpxaVMware vCenter AgentonTrueFalse
xorgX.Org ServeronFalseFalse
1.4.3.5.3 Authentication Services
DomainDomain MembershipTrusted Domains
LAB.LOCALOk

1.5 Distributed Virtual Switches

The following section provides information on the Distributed Virtual Switch configuration.

VDSwitchDatacenterManufacturerVersionNumber of UplinksNumber of PortsHost Count
DSwitchDatacenterVMware, Inc.6.5.04203
DSwitch 1DatacenterVMware, Inc.5.5.0280

1.5.1 DSwitch

1.5.1.1 General Properties

NameDSwitch
DatacenterDatacenter
ManufacturerVMware, Inc.
Version6.5.0
Number of Uplinks4
Number of Ports20
MTU1500
Network I/O Control EnabledFalse
Discovery ProtocolCDP
Discovery Protocol OperationListen
Connected Hosts192.168.1.111, 192.168.1.112, 192.168.1.113

1.5.1.2 Uplinks

VDSwitchVM HostUplink NamePhysical Network AdapterUplink Port Group
DSwitch192.168.1.111Uplink 1 DSwitch-DVUplinks-21
DSwitch192.168.1.111Uplink 2vmnic1DSwitch-DVUplinks-21
DSwitch192.168.1.111Uplink 3 DSwitch-DVUplinks-21
DSwitch192.168.1.111Uplink 4 DSwitch-DVUplinks-21
DSwitch192.168.1.112Uplink 1 DSwitch-DVUplinks-21
DSwitch192.168.1.112Uplink 2vmnic1DSwitch-DVUplinks-21
DSwitch192.168.1.112Uplink 3 DSwitch-DVUplinks-21
DSwitch192.168.1.112Uplink 4 DSwitch-DVUplinks-21
DSwitch192.168.1.113Uplink 1 DSwitch-DVUplinks-21
DSwitch192.168.1.113Uplink 2vmnic1DSwitch-DVUplinks-21
DSwitch192.168.1.113Uplink 3 DSwitch-DVUplinks-21
DSwitch192.168.1.113Uplink 4 DSwitch-DVUplinks-21

1.5.1.3 Security

VDSwitchAllow PromiscuousForged TransmitsMAC Address Changes
DSwitchFalseFalseFalse

1.5.1.4 Traffic Shaping

VDSwitchDirectionEnabledAverage Bandwidth (kbit/s)Peak Bandwidth (kbit/s)Burst Size (KB)
DSwitchInFalse100000000100000000104857600
DSwitchOutFalse100000000100000000104857600

1.5.1.5 Port Groups

VDSwitchPortgroupDatacenterVLAN ConfigurationPort BindingNumber of Ports
DSwitchDPortGroupDatacenterVLAN 8Static8
DSwitchDSwitch-DVUplinks-21DatacenterVLAN Trunk [0-4094]Static12

1.5.1.6 Port Group Security

VDSwitchPort GroupAllow PromiscuousForged TransmitsMAC Address Changes
DSwitchDSwitch-DVUplinks-21FalseTrueFalse
DSwitchDPortGroupFalseFalseFalse

1.5.1.7 Port Group NIC Teaming

VDSwitchPort GroupLoad BalancingFailover DetectionNotify SwitchesFailback EnabledActive UplinksStandby UplinksUnused Uplinks
DSwitchDPortGroupLoadBalanceSrcIdLinkStatusTrueTrueUplink 1
Uplink 2
Uplink 3
Uplink 4

DSwitchDSwitch-DVUplinks-21LoadBalanceSrcIdLinkStatusTrueTrue  Uplink 1
Uplink 2
Uplink 3
Uplink 4

1.5.1.8 Private VLANs

Primary VLAN IDPrivate VLAN TypeSecondary VLAN ID
1Promiscuous1
1Isolated2
1Community3

1.5.2 DSwitch 1

1.5.2.1 General Properties

NameDSwitch 1
DatacenterDatacenter
ManufacturerVMware, Inc.
Version5.5.0
Number of Uplinks2
Number of Ports8
MTU1500
Network I/O Control EnabledFalse
Discovery ProtocolCDP
Discovery Protocol OperationListen
Connected Hosts

1.5.2.2 Security

VDSwitchAllow PromiscuousForged TransmitsMAC Address Changes
DSwitch 1FalseFalseFalse

1.5.2.3 Traffic Shaping

VDSwitchDirectionEnabledAverage Bandwidth (kbit/s)Peak Bandwidth (kbit/s)Burst Size (KB)
DSwitch 1InFalse100000000100000000104857600
DSwitch 1OutFalse100000000100000000104857600

1.5.2.4 Port Groups

VDSwitchPortgroupDatacenterVLAN ConfigurationPort BindingNumber of Ports
DSwitch 1DPortGroup 1Datacenter Static8
DSwitch 1DSwitch 1-DVUplinks-24DatacenterVLAN Trunk [0-4094]Static0

1.5.2.5 Port Group Security

VDSwitchPort GroupAllow PromiscuousForged TransmitsMAC Address Changes
DSwitch 1DPortGroup 1FalseFalseFalse
DSwitch 1DSwitch 1-DVUplinks-24FalseTrueFalse

1.5.2.6 Port Group NIC Teaming

VDSwitchPort GroupLoad BalancingFailover DetectionNotify SwitchesFailback EnabledActive UplinksStandby UplinksUnused Uplinks
DSwitch 1DPortGroup 1LoadBalanceSrcIdLinkStatusTrueTrueUplink 1
Uplink 2

DSwitch 1DSwitch 1-DVUplinks-24LoadBalanceSrcIdLinkStatusTrueTrue  Uplink 1
Uplink 2

1.6 vSAN

The following section provides information on the vSAN configuration.

1.6.1 VSAN-Cluster

NameVSAN-Cluster
TypeAll-Flash
Version6.6.1
Number of Hosts3
Stretched ClusterFalse
Disk Format Version5
Total Number of Disks6
Total Number of Disk Groups3
Disk Claim ModeManual
Deduplication and CompressionFalse
Encryption EnabledFalse
Health Check EnabledTrue
HCL Last Updated5/08/2018 5:03:21 AM

1.7 Storage

The following section provides information on the VMware vSphere storage configuration.

NameTypeTotal Capacity GBUsed Capacity GBFree Space GB% UsedHost Count
vsanDatastorevsan23.982.6321.3410.983

1.7.1 Datastore Specifications

NameDatacenterTypeVersionStateSIOC EnabledCongestion Threshold ms
vsanDatastoreDatacentervsan AvailableFalse

1.8 Virtual Machines

The following section provides detailed information on Virtual Machines.

1.8.1 Test_1

NameTest_1
Operating System
Hardware Versionv13
Power StatePoweredOff
VM Tools StatustoolsNotInstalled
Host192.168.1.112
Parent FolderDiscovered virtual machine
Parent Resource PoolResources
vCPUs1
Cores per Socket1
Total vCPUs1
CPU ResourcesNormal / 1000
CPU Reservation0
CPU Limit0 MHz
Memory Allocation4 GB
Memory ResourcesNormal / 40960

1.8.2 Test_2

NameTest_2
Operating System
Hardware Versionv13
Power StatePoweredOff
VM Tools StatustoolsNotInstalled
Host192.168.1.111
Parent Foldervm
Parent Resource PoolResources
vCPUs1
Cores per Socket1
Total vCPUs1
CPU ResourcesNormal / 1000
CPU Reservation0
CPU Limit0 MHz
Memory Allocation4 GB
Memory ResourcesNormal / 40960

1.8.3 Test_3

NameTest_3
Operating System
Hardware Versionv13
Power StatePoweredOff
VM Tools Status
Host192.168.1.113
Parent Foldervm
Parent Resource PoolResources
vCPUs1
Cores per Socket1
Total vCPUs1
CPU ResourcesNormal / 1000
CPU Reservation0
CPU Limit0 MHz
Memory Allocation4 GB
Memory ResourcesNormal / 40960

1.8.4 VM Snapshots

Virtual MachineNameDescriptionDays Old
Test_2VM Snapshot 3%252f9%252f2018 3:00 PM UTC+11:00 149

1.9 VMware Update Manager

The following section provides information on VMware Update Manager.

1.9.1 Baselines

NameDescriptionTypeTarget TypeLast Update TimeNumber of Patches
Critical Host Patches (Predefined)A predefined baseline for all critical patches for HostsPatchHost28/02/2017 9:35:00 PM71
Non-Critical Host Patches (Predefined)A predefined baseline for all non-critical patches for HostsPatchHost28/02/2017 9:35:00 PM236
VMware ESXi 6.5.0 U2 (vSAN 6.6.1 Update 2, build 8294253)VMware ESXi 6.5.0 U2 (vSAN 6.6.1 Update 2, build 8294253)PatchHost23/05/2018 9:28:38 AM1

Bonne documentation 😄
